ADDITIONAL PRODUCT INFORMATION:
- Multi-zone valve relay and boiler operating control for multiple zone hydronic heating systems
- Interfaces with low voltage thermostats or any other low voltage controllers having a switching action
- Controls from 3 to 6 zones (model dependent)
- System circulator pump and secondary pump is turned on whenever any zone calls for heat
- Install the ZVR relay together with our z-one valves and qualify for an industry exclusive five year warranty
- Led indicators provide functional status and easy system troubleshooting
- ZVR series is a perfect match with caleffi z-one motorized zone valves
- High capacity 40 VA transformer standard for 3 and 4 zone models
| UPC: |
8016615438154 |
| Weight: |
4.81 lbs. |
| Made In: |
Canada |
| Voltage: |
120v |
| Dry Contact Eating Aux Xx Zone 1 E S: |
120 VAC, 2 A |
| Replaceable Fuses: |
Automatic |
| Safetylist: |
cETLus Intertek Listed 4009064 |
| Switch Contact Rating: |
20 A Combined, 5A at 120 VAC Each Pump Output |
| Transformer Voltage: |
24 VAC |
*OVERSTOCK PRODUCTS - NO WARRANTY AVAILABLE CONTACT MANUFACTURER FOR ANY QUESTIONS REGARDING PRODUCT
